Plug & Play ZHAGA
Twist Lock
Gateway Free
Installation
Open Cellular
Network
Up to 60%
Energy Savings
Smart City
Ready
BOSUN® IoT ZHAGA controller uses open standard telecom network. Use of cellular network allows this IoT controller to connect directly to a local cell tower (2G/ 4G/ NB-IoT). This eliminates the need for dedicated Gateways.
Standard ZHAGA street light controller (7-pin, ANSI c136.41) dimming receptacle of BOSUN outdoor light controller guarantees swift installation and universal luminaire compatibility.
ZHAGA Controller
Highly Compatibility
BOSUN® IoT ZHAGA controller is a perfect smart city street lighting solution that is quick and easy to deploy throughout your city.
4G/LTE (Solar optional) solution featuring the base station for dissemination of signals to every single street light. The signal spreads out in concentric circles that is able to cover a few roads at the same time. The transmission is way faster through a direct connection. The terminal is equipped to upload data and real-time status to the management control system. Realizing real-time remote control through PC or APP management system. There is no need for local Gateways. This significantly reduces the cost and hassle of maintaining a local network infrastructure, since local operators manage and maintain the network.
PLC Solution
LoRa-MESH solution consists of a control system for intelligent management remotely by PC or APP through a point-to-point connection. The signal of the LoRa-MESH solution spreads out in linear propagation. Mostly used on straight roads that stretch on and on. Featuring various types of connection methods for realizing customized lighting design. One is to connect the centralized controller through a data cable to the ZHAGA controller, second one is a wireless connection through the gateway or centralized controller. Different application scenarios for different connection methods. The solar version of LoRa-MESH has a different point and is the substitute for the original driver with the Pro-Double MPPT solar charge controller. Know more about our patented technology - Pro-Double MPPT solar charge controller.
LoRa-MESH
(Solar Optional)
PLC solution connection from the management control system through a centralized controller with an electric cable and data cable, cable connection makes it more stable. One of the highlight specificities is the PLC solution has a single light head or dual light head optional, depending on the situation of the city road infrastructure.
Open Standard Cellular Network 3G/4G/5G Of ZHAGA Controller to directly connect to street light. Quick responsiveness and easy management.
Public infrastructure demands high reliability and security. Therefore, the ZHAGA street light controller uses the standardized 3GPP cellular network to connect an individual street light to our light management platform.
The ZHAGA street light controller automatically selects the best available local connectivity: Edge (EGPRS), LTE Cat M1 or NB-IoT (NB2). Cellular networks comply with the highest global security standards. It is used by billions of devices today.
They offer long-range, deep coverage, high availability, and managed Low Power Wide Area network (LPWAN).
ZHAGA Controller
Unlike proprietary network providers (e.g. LoRA, Sigfox, Zigbee, Wi-Sun and UNB), ZHAGA street light controller connects directly with Gebosun® smart city light management platform via a local cellphone tower.
ZHAGA controller connects directly with the signal source, then straight up to the server and connects to the Gebosun® smart city light management platform such as iPad, smartphone, and computer. The NEMA controller appears to have a cylindrical design, which is commonly suitable for many devices to be compatible.
ZHAGA ControllerAd Hoc RF
ZHAGA controller supports self-organizing network radio frequency communication, achieving 99% online rate of lighting control
ZHAGA street light controller provides a self-organizing network that is supported between multiple single-lamp controllers. The effective RF transmission distance of the light controller is 500~1000 meters, which can meet the data exchange and relay between two adjacent street lamps. The single-lamp control system based on wireless self-organizing network technology can achieve an online rate of more than 99%.
Automatically on or off when a car passes by, it perfectly realizing "the lights move with the car"
100% brightness when vehicle pass
In relevance with the intelligent infrared sensors, the ZHAGA street light controller perfectly controls the lights to follow the movement of the vehicle: the lights will automatically turn on or off when the vehicle approaches or leaves. It can adaptively expand a lighting area in real-time according to the direction of the vehicle, and dynamically turn on 10 lights in advance as the vehicle moves, with the advanced lighting area being approximately 400 meters. The lights follow the movement of the vehicle, which not only ensures driving safety but also achieves an energy-saving rate of more than 80%. It's a win-win project for urban infrastructure.
ZHAGA Controller Sensing function
30% brightness without movement detected
Multiple Dimming Mode
· 0-10V
· 1-10V
· DALI
Two Street Light Colors
· DALI 2.0
· D4i
· SR
Create the night ambiance with the tender soft warm light for the citizens. Also high-brightness cold light for night illumination.
Choose from a broad spectrum of colors or any shade of white to find the right tone(RGBW).
Adjust colors based on:
Profiles
Specific Days
Festive Events
Human Movements (Motion Sensing）
Switch Cold Light on sunny night
Switch Warm Light on rainy night
ZHAGA Controller
Auto-Positioning
Built-in GPS within BOSUN® ZHAGA controller supports automatic registration. This helps a local electrician to install the controllers without expert knowledge or training.
No need for a field application tool
No network engineering needed
ZHAGA automatically receives its geo-location
Warm light is easier for the eyes to process. In fact, warm light wavelengths hit the retina in the perfect spot. That makes this warm LED solar street light the best for rainy days.
Cold light is perfect for performing activities where it is necessary to maintain concentration and have good visibility. A cold light ensures optimal illumination for the best level, providing high brightness for outdoor spaces.
Withstand Extreme Environments
ZHAGA controller has IP65 protection and V-O flame retardant. External flames are extinguished within 10 seconds, and the shell does not melt or deform. It has passed the harsh high and low-temperature extreme environment durability test and is stable and reliable in operation regardless of extreme heat or cold.
Weatherproof
V0 Flame retardant
High and low temperature resistance
IP65 Waterproof
Up to 60% energy savings and CO2 prevention
Up to 50% reduction in maintenance costs
Total control of entire lighting infrastructure
Reduce
light pollution
Ability to dim street lights automatically through pre-defined schedules or other dimming options maximizes energy savings and also helps reduce CO2 emissions.
Proactive alerts and notifications for faults, alarms and outages help to optimize maintenance and reduce costs by up to 50%.
ZHAGA controller monitors, manages and controls each individual light point or a group of solar street lights remotely from a single location.
During the off-peak hours, street lights dim low brightness for energy-saving. Thereby reducing light pollution and benefitting nocturnal life.
Tighten and Easy to install
BOSUN IoT ZHAGA street light controller fully complies with ANSI C136.41 standard.
The installation of ZHAGA interface single lamp controller does not require screws. Insert it into the slot and tighten it to fix it. Installation/repair/replacement is very convenient.
This product must be used with a ZHAGA twist lock base that meets the requirements of ANSI C136.41.
· Plug and play installation
· No special tool or training is needed
· Works with any ZHAGA-compatible LED luminaire/lighting fixture (5-pin or 7-pin ZHAGA Receptacle)
Powerful data collection and monitoring capabilities
The ZHAGA controller supports monitoring the input voltage, current, power and other data of the lamp, accurately grasps the status and changes of the solar street light, and also adopts the internationally advanced AES128 encryption algorithm to effectively ensure the security of data transmission.
ZHAGA Controller Advanced encryption algorithm
Monitor lamp input voltage
Monitor lamp input current
Monitor lamp input power
AES128 encryption algorithm
Energy Analytics State Monitoring
Mains Current
Energy analytics and luminaire state monitoring with an inbuilt energy meter, you can accurately monitor and measure the energy usage and performance status of street lights in Gebosun® smart city control system.
Advanced Switching and Dimming Options
Cities often have different types of luminaire and driver. Power grid infrastructure may also vary across the city. BOSUN® IoT controller offers you excellent flexibility in selecting suitable light profiles to meet local requirements.
Twilight (photocell/ ambient light sensor)
AstroClock (astronomical clock)
Time-based light scene
Calendar-based schedules
Central ALS (photocells in city)
Adaptive (motion sensor)
Emergency (HiLight app)
Autonomous mode
Energy Consumed (Active, Reactive) | Power Factor
Power (Active, Apparent) | Driver Stat Counter
Driver Temperature | Lamp / Driver Operating Time
Smart Street Light
Centralized Concentrator for Smart Street Lights | Gebosun
Wireless Controller with LED driver and communicate with LCU by LoRa-MESH
Wholesale Pro-Double MPPT（IoT) Solar Charge Controller Manufacturers | Gebosun
Highly Compatibility Wireless IOT ZHAGA Controller For Smart Street Light
FAQs
What is a ZHAGA controller?
ZHAGA controller is a compact, plug-and-play device that enables remote control and monitoring of smart LED street lights via a ZHAGA socket.
What are the advantages of using a ZHAGA controller?
It can easily monitor and control lights from a central system. Adjust brightness levels based on ambient conditions or usage. Receive alerts for failures or maintenance needs in time and precise positioning.
How does the ZHAGA controller help in smart city development?
It enables integration with broader smart city platforms, allowing data collection on traffic, energy consumption, and environmental conditions, aiding in efficient city management. More info about smart city.
What kind of data can be monitored through a ZHAGA controller?
You can monitor real-time data such as energy consumption, light performance, system health, and any faults or failures, enabling proactive maintenance.
